A program is a passive thing: a file on disk containing instructions and initial data. A process is that program in motion, and it carries state the file never had. Two users running the same editor binary produce two processes with separate memory, separate open files and separate positions in the instruction stream.
The abstraction exists so that a limited number of CPUs can be shared by many programs. The operating system gives each process the illusion of owning a CPU and a private address space, and multiplexes the real hardware underneath. Getting that illusion right is most of what the process subsystem does.
A process’s machine state has three parts you should be able to name in an exam:
A process moves through a small set of states. The three that matter are:
Two more appear in most textbook diagrams: new, while the process is being created and admitted, and terminated (often called the zombie state on Unix), where the process has finished but its exit status has not yet been collected by its parent.
The transitions are worth learning as a set. Ready to running is a schedule; running to ready is a deschedule, which happens on a timer interrupt or when a higher-priority process becomes ready. Running to blocked happens when the process issues a blocking I/O request. Blocked to ready happens when that I/O completes. Note that a blocked process never goes directly back to running; it must pass through ready and be chosen by the scheduler.
The operating system tracks each process with a data structure usually called the process control block, or PCB. On Linux the equivalent structure is task_struct. It holds everything the kernel needs to suspend a process and resume it later as if nothing happened:
The saved register context is the critical field. It is what makes a process resumable, and it is what gets written and restored during a context switch.
Unix separates process creation from program loading, which surprises people coming from other systems but turns out to be a clean design.
fork() creates a near-identical copy of the calling process. The child gets its own address space, initially a copy of the parent’s, and its own PID. The call returns twice: in the parent it returns the child’s PID, and in the child it returns 0. That difference in return value is the only thing distinguishing the two paths.
pid_t rc = fork();
if (rc < 0) {
// fork failed
} else if (rc == 0) {
// child executes here
} else {
// parent executes here, rc holds the child's PID
}The order in which parent and child run after the fork is decided by the scheduler and is not guaranteed. Code that depends on one running first is incorrect.
exec() replaces the current process image with a new program. It does not create a process. The PID stays the same; the code, static data, heap and stack are all overwritten by the new executable, and execution begins at its entry point. A successful exec never returns, because there is no longer any code to return to.
exit() terminates the calling process and hands an exit status to the kernel. wait() lets a parent block until a child terminates and collect that status. Until the parent calls wait, the terminated child remains as a zombie: its PCB is retained purely to hold the exit status. A parent that never waits leaves zombies accumulating in the process table.
The reverse case is an orphan, a child whose parent exited first. Orphans are re-parented to the init process, which waits on them routinely, so they are cleaned up.
A context switch is the mechanism by which the operating system stops one process and starts another. The steps are:
The switch is not free. Beyond the direct cost of saving and restoring registers, there is an indirect cost: the new process finds the CPU caches and the TLB filled with the previous process’s data, and runs slowly until they warm up. This indirect cost is often larger than the direct one, and it is the reason very small scheduling quanta hurt throughput.
The fork-then-exec split exists to give the shell a window in which to act. When you type a command, the shell:
fork() to create a child.exec() in the child to load the requested program.wait() in the parent, so the shell blocks until the command finishes and only then prints the next prompt.Redirection and pipes both work because the descriptor manipulation happens between the fork and the exec. A combined “create process and run program” call would leave nowhere to do it.
fork creates a process and returns twice. exec replaces the program and never returns. wait collects a child’s exit status.
